White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale

Looking for high-quality customized geotextile fabric for slope protection? Our factory offers a hot sale on 100GSM PP Pet nonwoven fabric in a variety of sizes.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Material
PP/Pet
Kind
Non-woven
Elongation
<100%
Width
1-6m
Length
50-300m
Quality
CE/ASTM/GM Available
Transport Package
Roll with Plastic Film or Bag.
Specification
80-1200g
Trademark
Dageng
Origin
Shandong
HS Code
5603941000
Production Capacity
50000 Square Mater Per Day

Product Description

White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot SaleProduct Introduction:

Usually, non woven geotextile refers to needle punched non-woven geotextile made from Polyester or polypropylene short curing fiber with the diameter of 6D to 12D and length of 54-64mm.
The producing process is to opening, carding and cluttering the short fibers to make them cross with each other, and then lapping to let the fibers normalize entangling, and at last needle punched with high speed. It is an effective and economical solution of separation, filtration, drainage, protection and reinforcement functions for engineering projects.


Application:

For Filtration:
When water passes from a fine-grained to a coarse grained layer, Non woven Geotextile can retain fine particles well. For an example, when water flows from a sandy soil into a Geotextile wrapped gravel drain.
For Separation:
It can separate two layers of soil with different physical properties. For an eample, the separation of road gravel from soft sub-base materials.
For Drainage:
It can drain liquid or gas from the plane of the fabric, which leads to draining or venting of the soil. For an example, the gas vent layer in a landfill cap.
For Reinforcement:
It can improve the load bearing capacity of a specific soil structure. For an example, the reinforcement of a retaining wall.


Package and delivery:

Package: Inner pipe + outside bag or film.
Delivery: 10 containers per month.
White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale

PP Short Fiber Needle Punched Nonwoven Geotextile: CE Certificate
Gram Weight g/m2 100 150 200 250 300 350 400 450 500 600 800
Tolerance of unit weight % -8 -8 -8 -8 -7 -7 -7 -7 -6 -6 -6
Thickness mm≥ 0.9 1.3 1.7 2.1 2.4 2.7 3 3.3 3.6 4.1 5
Tolerance of roll width % -0.5
Breaking strength KN/M ≥ 5.5 8 11 13.5 16 18.5 22 24.5 28 34 40
Elongation % 50-90
CBR bursting strength KN ≥ 0.15 0.45 0.5 0.6 0.7 0.8 0.9 1.1 1.3 1.6 2
Tearing strength KN≥ 0.45 0.65 0.9 1.1 1.25 1.4 1.6 1.8 2 2.2 2.4

PP High Strength Short Fiber Non woven Geotextile: CE Certificate
Weight g/m2 100
 (15%)
200
 (16%)
300
 (16%)
400
 (16%)
500
 (16%)
600
 (16%)
800
 (16%)
1000
 (16%)
Thickness mm 1.4-1.7 1.8-2.2 2.4-2.8 3-3.5 3.6-4 4-4.4 4.8-5.2 5.6-6
Grab Tensile Strength N≥ 450 900 1250 1600 2000 2400 3000 3600
Elongation % 50-90 50-100
Trapezoidal Tear N≥ 175 350 425 500 580 650 800 950
CBR Puncture Resistance KN≥ 1.25  2.5  3.5  4.3  5.3 6.2  7.1  8
Breaking Strength KN≥ 5.5 11 16 22 28 34 45 55
Elongation at breaking % 40-65 50-80
Puncture Strength N ≥ 220 430  665  900  1200  1430  1900  2350
Peel Strength N/5cm≥ 80 100
Resistance to Acid and Alkali % The Breaking Strength Resistance Rate ≥90%; Breaking elongation resistance rate ≥90%.
Equivalent Aperture (Dry sieve ) mm ≤0.1
Vertical Permeability Coefficient cm/s ≤0.2
Polyester Short Fiber Needle Punched Nonwoven Geotextile: CE Certificate
Gram Weight g/m2 100 150 200 250 300 350 400 450 500 600 800
Quality deviation per unit acreage % -8 -8 -8 -8 -7 -7 -7 -7 -6 -6 -6
Thickness mm≥ 0.9 1.3 1.7 2.1 2.4 2.7 3 3.3 3.6 4.1 5
Width deviation for range, % m -0.5
Mightiness at break, KN/M ≥ 2.5 4.5 6.5 8 9.5 11 12.5 14 16 19 25
Elongation at break, % 25-100
CBR bursting strength, KN ≥ 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.2 4
Effective aperture O90 0.07-0.20
Vertical osmotic coefficient,cm/s K*(10-1-10-3), K=1-9.9
Tearing strength, KN≥ 0.08 0.12 0.16 0.2 0.24 0.28 0.33 0.38 0.42 0.46 0.6
White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale
White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale White Black Geo Textile Roll Customized Size 100GSM PP Pet Nonwoven Geotextile Fabric for Slope Protection Hot Sale

FAQ:

Q: Are you factory or trading company?
A:  We are factory.
Q: Which country did you export?
A: Our products have been exported to many countries all over the world, including USA, Panama, Colombia, Chile, Peru, Ecuador, Russia, UK, Italy, France, Germany, Poland, Hungary, Turkey, Romania, Israel, India, Philippines, Singapore, Vietnam, Thailand, Indonesia, Australia, New Zealand...

Q: May I have your samples for testing?
A: Yes. We are glad to provide free samples within 3 days.

Q: What is your MOQ?
A: Normally, MOQ is one 20'GP container. But we also accept LCL for trial order.
Q: What's the payment term?

A:  T/T,L/C.
