PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

Welcome to our factory specializing in the production of high-quality {PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile} products. Get the best geosynthetic solutions here!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Features and Benefits
  • Product Parameters
  • Product Application
  • Company Profile
  • Customer Feedback
  • FAQ
Overview

Basic Info.

Model NO.
filament woven geotextile
Certification
CE
Feature
Corrosion Resistant, Oxidation Resistance, Wear-resistant
Usage
Insulation, Waterproof, Water Filter
Material
PET
Kind
Woven
Product Name
Filament Woven Geotextile
Length
50-200m
Width
2-6m
Function
Filtration ,Separation,Drainage, Reinforcement
Certificate
ISO9001,ISO14001
Weight
80-700G/M
Standard
GB/ASTM
Craft
Woven
Weft Rupture Strength
20-210 Kn/M
Longitudinal Rupture Strength
50-220 Kn/M
Longitudinal Elongation at Break
7±1—16±1
Latitudinal Elongation at Break
7±1—14±1
Sieve Sizeo90(O95)
0.05~0.5
Transport Package
Packed in The Woven Bags
Specification
5.8m*100m
Trademark
Jinruixiang
Origin
Shandong
Production Capacity
20000 Square Maters/ Day

Packaging & Delivery

Package Size
30.00cm * 30.00cm * 1.00cm
Package Gross Weight
1.000kg

Product Description



Product Description

PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

PP Woven Geotextile
High tenacity woven series of products is woven by high strength PP yarn. High strength and good durability meets the strict requirements of long time design reinforcement engineerings. The raw materials-pp yarn is high strength and low creep.
Woven geotextiles offers immediate and cost effective solutions for most separation and also many stabilization applications. By providing as well as maintaining separation of the aggregate and subgrade soils, the system life of both paved as well as unpaved roadways is extended significantly.
In unpaved applications, the aggregate remains useful throughout the entire life of the job. Additionally, access to work sites remains trouble free through all types of weather. Stabilization is provided primarily by their high strength at low elongation that distributes loads and reduces or eliminates rutting.
Most all types of geotextiles are excellent separators of aggregate and subgrade. However, only woven geotextiles have the high modulus (resistance to stretch) necessary to provide stabilization over soft or poorly drained soils.
Features and Benefits

PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

Woven polypropylene geotextiles are designed to provide cost-saving solutions in a wide range of applications as well as varying site conditions.
1. Separation: Prevents dissimilar materials from intermixing, thereby extending the system lives of both paved as well as unpaved applications.
2. Stabilization: Higher tensile modulus at low strains delivers immediate support and also load distribution in moderate subgrade conditions.
3. Durability: Excellent resistance to installation damage assures long-term performance.
4. Cost Savings and Effectiveness: Low-cost and High performance assures savings in structural materials, labor costs and also future maintenance for many civil engineering applications.
Product Parameters
Index HKWP41S HKWP65S HKWP85S HKWP65/60 HKWP85/80 HKWF50/20 HKWF50/30 HKWF85/30
  250 300 390 290 265 180 200 300
Breaking strength (kN/m) Warp wise 50 65 85 65 85 50 50 85
Warp direction 60 65 85 60 80 20 30 35
Elongation at break (%) Warp wise 10±1 10±1 10±1 10±1 10±1 13±1 16±1 14±1
Warp direction 7±1 8±1 8±1 8±1 8±1 8±1 10±1 12±1
Trapezoid tear strength (N) Warp wise 700 700 700 700 900 500 600 1000
Warp direction 400 650 650 650 1100 400 500 400
Grip strength (N) Warp wise 1940 2200 2900 2200 2900 1800 1800 2300
Warp direction 1900 1550 2250 1500 2200 700 1000 1300
Static bursting strength (CBR)(KN) 6 8 10 7.8 10 3 3.5 4.5
Effective aperture (O90)(mm) 0.6 0.48 0.43 0.5 0.45 / / /
Permeability (Q50)(L/m2/s) 38 55 42 57 46 / / /
Uv resistance
(500-hour strong retention rate) (%)
90 90 90 90 90 90 90 90
Product Application
PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile
PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile
PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

1. Road Work
Geotextiles are used in the construction of the road. It reinforces the soil by adding tensile strength to it. It is used as a
rapid de-watering layer in the roadbed, the geotextiles need to preserve their permeability without losing their separating functions.
2. Railway Works
The woven fabrics or the non-woven ones are used to separate the soil from the sub-soil without impeding the groundwater circulation where the ground is unstable. Enveloping individual layers with fabric prevents the material from wandering off sideways due to shocks and vibrations from running trains.
3. Agriculture
It is used for mud control. For the improvement of muddy paths and trails used by cattle or light traffic, nonwoven fabrics are used and are folded by overlapping to include the pipe or a mass of grit.
4. Drainage
The use of geotextiles to filter the soil and a more or less single-size granular material to transport water is seen as a viable alternative to conventional systems. Geotextiles perform the filtering mechanism for drainages in earth dams, on roads and highways, in reservoirs, behind retaining walls, in deep drainage trenches, and in agriculture.
5. River, Canals, and Coastal Works
Geotextiles protect river banks from erosion due to currents or lapping. When used in conjunction with natural or artificial enrockments, they act as a filter.

Company Profile

PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

Customer Feedback

PP Polypropylene Knitted Filament Woven Sludge Baffle Curtain Geogrids Geocontainer Geobag Geomattress Geotube Geotextile

FAQ

Q : Are you a factory or trading company?
A : We are a professional manufacturer that specialized in geomembrane, geotextile, composite geomembrane etc with ISO9001 certificate more than 15 years.
Q : Where is your factory located? How can I visit there?
A : Our facoty is located is No.10 Yuanshan Road High-tech Development Zone, Laiwu District, Jinan City China. You can take the plan to Jinan Yaoqiang International Airport, then we can pick you up.
Q : Could you send the sample before order confirmation?
A : Yes, we'd love to send a free sample to you for an evaluation if you need.
Q : How about the delivery time?
A : General within 3-7 days after received the deposit.
Q : Can you produce the product according to customers' requirements?
A : Sure, we are professional manufacturer, OEM and ODM are both welcome.
Q : Are you the Gold and Assessed supplier on alibaba?
A : Yes. We are the gold and assessed supplier on alibaba and has got the factory report by SGS.
