Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid

Our Polypropylene/Polyester Needle Punched Filament Geotextile Fabric is ideal for road construction with geogrid. We are a factory committed to providing high-quality products.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
nonwoven geotextile
Material
PP
Kind
Non-woven
Width
1-8m
Length
as Your Request
Unit Weight
80GSM-1000GSM
Samples
Available
Transport Package
Woven Geotextile
Specification
240g/m2
Trademark
Purest Nonwoven
Origin
China
HS Code
5603949000
Production Capacity
10000suqre Mater/Day

Product Description


Continuous Filament spunbonded nonwoven geotextile is a kind of non-woven fabric reinforced by polyester filament after laying mesh. It does not need heat treatment and does not contain any chemical additives.Filament needle punched nonwoven geotextile using all new polyester resin spunbonded continuous filament needle punched geotextiles are manufactured by the extrusion of fibers which are then laid down on a manufacturing "bed" and then needle punched from both top and bottom to entangle the fibers to produce a dimensionally stable geotextile.



Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid

Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid

Product Name Polyester and pp geogextile
Material polyester or pp or mixed or recycled
Surface both sides smooth / both sides textured / one side smooth, the other side textured / as your request
Thickness 1mm - 5.0mm
Size Width: 4M - 10M
Length: 50M - 200M (or as request)
Color Black, White, Blue, Green, Grey , etc
MOQ 1000sqm per thickness
Certificate CE / ISO 9001
Packing In PP woven bag or as request
Samples Free samples available
Delivery Time about 15 days after received the 30% deposit
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid


Unit weight
(g/sqm)

Thickness
(mm)

Breaking strength
(kn/m)

CBR burst strength(KN)

Elongation at break(%)

Tear Strength
(KN)
100 0.9 2.5 0.3 25-100 0.08
150 1.3 4.5 0.6 25-100 0.12
200 1.7 6.5 0.9 25-100 0.16
250 2.1 8.0 1.2 25-100 0.20
300 2.4 9.5 1.5 25-100 0.24
350 2.7 11.0 1.8 25-100 0.28
400 3.0 12.5 2.1 25-100 0.33
450 3.3 14.0 2.4 25-100 0.38
500 3.6 16.0 2.7 25-100 0.42
600 4.1 19.0 3.2 25-100 0.46
800 5.0 25.0 4.0 25-100 0.60

Main Features:

1)anti-aging, the product has very high anti-ultraviolet radiation ability, not easy to degradation.

2) High temperature resistance to up to 230ºC maintaining structure stability and original physical properties.

3) High flat drainage and vertical permeability.

4) High creep resistance.

5) Resistance of erosion of chemicals in soil with the corrosion of gasoline and diesel etc.

6) High elongation under certain stress, thus able to adapt to uneven and irregular bases.


Application:

Major functions: Separation, filtration, drainage, reinforcement, protection, and liquid barrier

1) Filtration The filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.

2) Separation The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.

3)Adding muscle The highway, railway, soil-stone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth body stability.

4)Protection It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away.

Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid



Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid




Polypropylene/Polyester Needle Punched Filament Geotextile Fabric Used for Road Construction with Geogrid
