Basic Info.
Model NO.
RGW-Z0011
Warranty Year
3 Years
Place of Origin
Shanghai,China
Instrument Classification
Class II
Safety Standard
GB/T18830-2009
Transport Package
Wooden Box
Trademark
RGW
Origin
China
Production Capacity
10000PCS/Month
Product Description
Technical data | unit | 700 lamp head | 500 lamp head |
| Spot center illumination in color temperature 5000K | Lux | 160,000--200,000 | 120,000-180,000 |
Color temperature | K | 3500-5500 | 3500-5000 |
Ra | 97 | 97 | |
50% Spot diameter d50 | mm | 150 | 150 |
10% Spot diameter d50 | mm | 300 | 300 |
Lighting adjustment |
| 1%-100% | 1%-100% |
| Illuminance depth | cm | 130 | 100 |
| Illuminance adjusting range | % | 25-100 | 25-100 |
| Ultraviolet irradiance wavelength under 40nm | W | ≤0.002 | ≤0.002 |
Focal distance adjusting mode | Manual/electric(optional) | Manual/electric(optional) | |
| Beads power | W | 1W/unit×60beads | 1W/unit×45beads |
| Lamp head temperature |
| Less than 2 ºC | Less than 2 ºC |
| Power supply | 110V/220V 50Hz/60Hz | 110V/220V 50Hz/60Hz | |
| Input power | W | 100 | 100 |
| LED average life | H | ≥100,000 | ≥100,000 |
| Installation ceiling height | m | 2.65-3.2 | 2.65-3.2 |
