Basic Info.
Model NO.
PET400-400
Gram Weight
1700GSM
Structure
Fabric Form
Grid Size
40X40mm
Typical Uses
Highway & Railraod Embankment, Bridge Abutment
Breaking Strength in Md
400kn/M
Breaking Strength in CD
400kn/M
Breaking Elongation
Less 13%
Max Width
5.85m
Coating Materials
PVC
Transport Package
Plastic Bag
Specification
CE
Trademark
Utek
Origin
China
HS Code
5903
Production Capacity
10000000m2
Product Description
Polyester geogrids are made of high strength, high modulus and low shrinkage polyester yarns. The yarns are coated with a PVC material to resist biological degradation. It has a high resistance to creep.
Biaxial grids are perfect for applications where forces may act upon the grid from a variety of directions such as widening a road over soft soils, or adding a turn lane.Highway & Railroad Embankments
Landfills, Dams, Dikes & Levees
Bridge Abutments
| Specification | PET 20-20 | PET 200-200 | PET 400-400 | PET 600-600 | PET 1000-1000 | |
| Breaking strength (kN/m) | MD | 20 | 200 | 400 | 600 | 1000 |
| CD | 20 | 200 | 400 | 600 | 1000 | |
| Breaking elongation ( % ) | ≤ 13 | ≤ 13 | ≤ 13 | ≤ 13 | ≤ 13 | |
| Grid size (mm x mm) | 25x25 / 40x40 / 50x50 | |||||
| Max. width (m) | 5.85 | 5.85 | 5.85 | 5.85 | 5.85 | |
| Coating | PVC | PVC | PVC | PVC | PVC | |
