PRODUCTS DETAILS

  • Overview
  • Product Description
  • Technical Sheet
  • Feedback
  • Company Profile
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Model NO.
GH-1c
Color
Black
Application
Retaining Wall, Dam, Railway, Highway
Function
Distributing Load, Anti-deforming, Non-skid
Feature
Corrosion Resistant, Oxidation Resistance, Chemical Stability, Wear-resistant
Material
HDPE
Height
5cm, 7.5cm, 10cm, 15cm, 20cm, 25cm, 30cm
Welding Distance
330mm, 350mm, 400mm, 450mm, 500mm, 600mm, 660mm
Surface Treatment
Smooth, Textured, Perforated
Custom Colors
Black, Yellow, Green
Thickness
Greater Than 1.1mm
Product Name
Plastic HDPE Geocell Gravel Grid
Sheet Thickness
1.1mm,1.2mm,1.5mm
Package
as Customer Demand
Sample
Freely
MOQ
2000m2
Description
Plastic Parking Grass Grid Geocell
Certifications
CE/ISO14001/ISO9001
Model Number
HDPE Geocell
Peel Strength of Welding Point
1000-1420n/10cm
Transport Package
Fumigation-Free Pallets
Specification
20m2/Bundle
Trademark
SDJRX
Origin
China
HS Code
3925900000
Production Capacity
12000m2/Day

Packaging & Delivery

Package Size
120.00cm * 100.00cm * 150.00cm
Package Gross Weight
800.000kg

Product Description


Geocell Dam Construction Material Cellular Geocell Supplier
Product Description

Geocell is a three-dimensional mesh compartment structure geocell formed by reinforced HDPE sheet material, which is welded with high strength.

It has the ability to expand and contract freely, and can be transported in a retractable form, and can be tensioned into a mesh during construction and filled with loose materials such as soil, gravel and concrete to form a structural body with strong lateral restraint and large stiffness.

Geocell Dam Construction Material Cellular Geocell Supplier
Geocells have characteristics such as free expansion and contraction.
It can be shrunk and stacked during transportation, and can be tensioned into a mesh during construction and filled with loose materials such as soil, gravel and concrete to form a structural body with strong lateral restraint and large stiffness.
Geocell has high lateral restraint and anti-slip, anti-deformation, and effectively enhances the bearing capacity of roadbed and disperses the load.
In addition, high-quality geocells are light, wear-resistant, chemically stable, resistant to photo-oxidative aging, acid and alkali, and suitable for different soils and deserts and other soil conditions.

Geocell Dam Construction Material Cellular Geocell Supplier

Geocell treats half-fill and half-roadbed, roadbed in sandy areas, reinforcement of fill in the back of roadbed, roadbed in permafrost areas, treatment of wet sink roadbed in loess, saline soil and swelling soil.
Technical Sheet
Geocell Dam Construction Material Cellular Geocell Supplier
Product Type Height (mm) Sheet Thickness(mm) Welding Distance(mm) Peel strength of welding point(N/CM)
Smooth and Not Perforated 50~300 1.0~1.2 330~600 1000N/10CM
Smooth and perforated 50~300 1.0~1.2 330~600 1000N/10CM
Textured and Not Perforated 50~300 1.5~1.7 330~600 1420N/10CM
Textured and Perforated 50~300 1.5~1.7 330~600 1420N/10CM
Feedback

Geocell Dam Construction Material Cellular Geocell SupplierGeocell Dam Construction Material Cellular Geocell Supplier

Company Profile

Geocell Dam Construction Material Cellular Geocell Supplier

Geocell Dam Construction Material Cellular Geocell Supplier
Packaging & Shipping

Geocell Dam Construction Material Cellular Geocell Supplier

FAQ

Q: What are your common sizes?
A: Height 5cm/7.5cm/10cm/15cm/20cm/25cm/30cm
    Weld Distance 330mm/350mm/400mm/450mm/500mm/600mm/660mm
Q: What are your product standards?
A: Our products strictly follow the American standard, and the tensile strength of welded joints can reach 1420N/10cm.
Q: Do you company have minimum order quantity? How much?
A: We want to save you money on shipping costs. The best solution is to fill a container.
Q: Can I get some samples for testing?
A: Yes, we can provide you with free samples.
