Geocell Black HDPE Grid Geocell for Highway

Improve highway stability with our Geocell Black HDPE Grid. As a factory, we provide high-quality geocells for road construction.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
WANTONG
Type
Geocells
Product Name
Direct Factory Supply ASTM Standard HDPE Geocell
Thickness
1.1mm-1.6mm
Surface
Textured Smooth
Height
50mm~200mm
Description
Plastic Parking Grass Grid Geocell
Welding Distance
330mm-1000mm
Certifications
SGS
Package
Plastic Packing Belts
Corrosion Resistance
Excellent Corrosion Resistance
Certificate
Ce/ISO9001/ISO14001
Place of Origin
Shandong, China
Supply Ability
50000 Square Meter/Square Meters Per Month
Packaging Details
Pallet or Supplied Package with Your Requirement
Weld Spacing
330-356-400-445-500-660-712mm
Transport Package
Pallet Packaging
Specification
100-350/1.1
Trademark
wantong
Origin
Shandong
HS Code
3926909090
Production Capacity
50000square Meters Per Month

Product Description

Tested in multiple directions Strengthening expert  geocell for road  slope


(1)Product Description:


The geocell is a kind of 3d mesh cell structure formed by high strength welding of reinforced HDPE sheet material.
Generally by ultrasonic needle welding.Due to engineering needs, some holes in the diaphragm.

The geocell is a mesh cell structure formed by high strength HDPE or PP copolymer broadband, after strong welding or riveting
It retractable, transport can be folded up, when the use of the expansion and filling of soil and stone or concrete, with a strong lateral constraints and stiffness of the structure

It can be used as a cushion to increase the bearing capacity of soft foundation, or laid on the slope to form a slope protection structure, but also can be used to build retaining structure.

Geocell Black HDPE Grid Geocell for Highway Geocell Black HDPE Grid Geocell for Highway



(2)Product Function:

1.To stable the roadbed of railway.

2.To stable the roadbed of highroad.

3.To bear the load of dike or retaining wall.

4.To the improvement of shallow riverway.

5.To support the pipeline and sewer.

6.For the prevention of landslide by useing geocell as a heavy-duty hybrid force retaining wall

7.To be used as independent wall, wharf and breakwater, etc.

8.For the desert, beaches and the riverbed, the river bank`s regulation.

Geocell Black HDPE Grid Geocell for Highway Geocell Black HDPE Grid Geocell for Highway


Geocell Black HDPE Grid Geocell for Highway


(3)product performance

Our company cooperates with many companies,   Our product test results are fully up to international standards
The table is our test result

We are very strict with materials,  We do a lot of testing on raw materials
Geocell Black HDPE Grid Geocell for Highway


Material Properties Unit         Test Method
Cell Depth mm 75 100 150 200
Polymer Density

g/cm3                                    0.935-0.965 ASTM D1505
Enviromental Stress Crack Resistance Hours >400 ASTM D5397
Enviromental Stress Crack Resistance Hours 6000 ASTM D1693
Carbon Black Content % 1.5%-2.0% ASTM D1603
Nominal Sheet Thickness
Before Texturing
mm 1.27-5%+10% ASTM D5199
Nominal Sheet Thickness
After Texturingg
mm 1.52-5%+10% ASTM D5199
Strip Puncture Resistance N 450 ASTM D4833
Seam Peel Strength N 1065 1420 2130 2840 EN  ISO13426-18
Seam Efficiency % 100 GRI-GS13
Nominal Expanded Cell
Size(width×length)
mm 320×287.475×508 etc
Nominal Expanded Panel
Size(width×length)
m 2.56×8.35  4.5×5.0  6.5×4.5    6.1×2.44

(4)our Certifications
we have obtained ISO9001 certificate SGS certificate and CE certificate. Our products are widely applied in many fields, such as road, highway, airway, coal mine, water and soil conservation, water conservancy and basic construction.
Geocell Black HDPE Grid Geocell for Highway



(5)  Our Workshop
In recent years, our company has introduced a series of advanced equipment including 40 production lines for various kinds of geosynthetics products.Such as 28 geogrid production lines,2 geotextile production lines, 2 geomembrane production lines,1 geocell producttion lines, 2 nonwoven fabric roll production lines and 10 other new composite material production lines.




Geocell Black HDPE Grid Geocell for Highway Geocell Black HDPE Grid Geocell for Highway Geocell Black HDPE Grid Geocell for Highway



(6) Packaging & Shipping
We focus on every aspect of packaging,  We seek to ensure the safety of our goods in transit,  We can avoid any trouble in transit
Geocell Black HDPE Grid Geocell for Highway
