Basic Info.
Model NO.
SUS 3series
Application
Marine Structural Parts, Medical Tools, Sensors an
Edge
Slit edge
Stock
Stock
Transport Package
Wrap Pallet
Specification
thickness from 0.1mm, width customized
Trademark
Qirun
Origin
China
HS Code
72202020
Production Capacity
500000piece Per Year
Product Description
SUS630 stainless steel is widely used in air conditioner pressure switch diaphragm, automobile expansion valve diaphragm, air compressor shrapnel, elastic corrugated diaphragm, industrial socket shrapnel, thermostat
630 stainless steel belt
Density p: 7780kg/m
Linear expansion coefficient a (H900 heat treatment state): 10.8×10-6k-1 at 20-117ºC
20-200ºC.10.16×10-6 K-1
At 20-300ºC, 11.36×10-6 K-1
Thermal conductivity: 17W/(m.K) at 100ºC;
20W/(m.K) at 300ºC;
23W/(m.K) at 500ºC;
| Standard: | ASTM,AISI,DIN,EN,GB,JIS |
| Thickness: | 0.05mm-6.0mm |
| Width: | customized |
| Edge: | Slit edge/Mill edge |
| Surface: | 2B,BA,HL,Mirror,2D,No.1 |
| hardness | 2H 3/4H H EH DY BY Y |
| Delivery time | 10-15 days after receiving deposit by T/T or L/C. |
| Payment terms: | T/T,30%advanced payment before production and balance before shipment; OR Irrevocable L/C at sight. |
Density p: 7780kg/m
Linear expansion coefficient a (H900 heat treatment state): 10.8×10-6k-1 at 20-117ºC
20-200ºC.10.16×10-6 K-1
At 20-300ºC, 11.36×10-6 K-1
Thermal conductivity: 17W/(m.K) at 100ºC;
20W/(m.K) at 300ºC;
23W/(m.K) at 500ºC;
