4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale

Get high-quality 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification for road construction sale. We are a factory specializing in geogrid production.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Elongation
<4
Mesh Size
25.4*25.4, or as Request.
Types
Self-Adhesive or Without Glue Available
Popular Roll Width
3.9m, 5.8m
Roll Length
50-300m
Transport Package
Inner Pipe + Outside Bag or Film
Specification
2-6m width
Origin
China
HS Code
7019909990
Production Capacity
20000m2 Per Day

Product Description


4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction SaleIntroduction:

Fiberglass Geogrid is a kind of plane warp knitted mesh material with alkali-free fiberglass yarn as main body and then coated with bitumen, also called asphalt geogrid. Fiberglass Geogrid gives full protection for the fiberglass matrix and greatly improves the Biaxial Geogrid mesh retaining wall's wear and shear resistance. The most significant performance is the compound properties of the fiberglass yarn and asphalt mixture, which protects the fiberglass base material sufficiently and enhances its abrasive resistance and anti-shear ability. Thus the material is used for road surface reinforcement and resist crack and rut avoiding which solves the problem of hard-to-protect of asphalt pavement.
For Fiberglass Geogrid, we have two kinds: normal one and the self-adhesive one:
For the self-adhesive type, there is a layer coating of self - pressure sensitive adhesive. Not only can keep the normal product's performance, but also ensure the Biaxial Geogrid Mesh Retaining Walls combine tightly with the contacting surface. Self-adhesive Fiberglass Geogrid has the features of construction convenient and paving leveling.
By the way, we have CE/ISO certificates for Fiberglass Geogrid.


Application Range:

1.It reinforces old asphalt concrete road surface as well as asphalt layer, and prevents damage;
2.It is used for rebuilding cement concrete road surface into composite road surface and restraining reflection caused by block contraction;
3.It is used in road expansion and improvement project, control cracks caused by old and new combination position or by uneven sedimentation;
4.It is used in soft soil base reinforcement treatment. It is favorable for soft soil water separation and concretion,restrains sedimentation effectively, distributes stress uniformly and improves overall strength of road base;
5.It is sued for preventing contraction crack caused by new road semi-rigid base layer, and reinforces and prevents road surface crack caused by foundation crack reflection.
4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale
Fiberglass Geogrid: (CE/ISO Certificates)
Specification 25-25 40-40 50-50 80-80 100-100 120-120 200-200 400-400
Intensity
(KN/M)
Warp 25 40 50 80 100 120 200 400
Weft 25 40 50 80 100 120 200 400
Elongation ( %) ≤4
Mesh Size (mm) 25.4*25.4;  12.7*12.7
Roll Width (m) 1/2/3.95/4/5.3/6
Roll Length (m) 50/100
Types  Regular/self-adhesive bitumen coating
4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale
4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale 4% Elongation 100kn Fiberglass Mesh Geogrid with CE Certification Geogrid for Road Construction Sale FAQ:

Q: Are you factory or trading company?
A:  We are factory direct sale.

Q: Which country did you export?
A: Our products have been exported to many countries all over the world, including USA, Panama, Colombia, Chile, Peru, Ecuador, Russia, UK, Italy, France, Germany, Poland, Hungary, Turkey, Romania, Israel, India, Philippines, Singapore, Vietnam, Thailand, Indonesia, Australia, New Zealand...

Q: May I have your samples for testing?
A: Yes. We are glad to provide free samples within 5 days. Usually we provide A4 size free sample. New Client needs to pay the air delivery cost.

Q: What is your MOQ?
A: Normally, MOQ is one 20'GP container. But we also accept LCL for trial order.

Q: What's the payment term?
A: Usually T/T, L/C.
