Easily Dedusting High Temperature P84/Polymide Non Woven Geotextile Filter Fabric

Get reliable P84/Polymide non woven geotextile filter fabric for high temperature applications. We are a factory specializing in easily dedusting products.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Width
Max 2.30m
Weight Range
300-800
Size
Customerization
Transport Package
Bags
Specification
50/100METER PER ROLL
Trademark
HAOTIAN
Origin
Taizhou
HS Code
56029000
Production Capacity
500000

Packaging & Delivery

Package Size
65.00cm * 23.00cm * 35.00cm
Package Gross Weight
1.200kg

Product Description


P84 polyimide needlefelts are excellent high temperature filter media in terms of performance, generally surpassing the other standard media with the exception of PTFE.

   P84 Fiber Features
Excellent steady under high temperature and resistance to acid
P84 can operate continuously, under practical and low acid working conditions, at temperatures up to 500 F(260).
High filtration efficiency, high tensile strengh
The complex cross sectional shapes create 30-90% more collection surface area when compared to round or oval shaped fibers.
Low back washing pressure, maximun flexibility
The unique tri-lobal fiber structure of P84 provides customers with high efficiency filtration, low pressure drop, and reduced cleaning energy.
Excellent dust cake release
P84 has irregular, tri-lobal fibers that provide better collection efficiencies and enhanced dust cake release properties.


Compositions

P84/P84 scrim

P84/galss scrim

Weight (g/m2)

450

500

550

800

850

900

Thickness (mm)

2.1

2.3

2.5

2.5

2.8

3.0

Permeability (m3/m2/min)

19

15

12

16

13

10

Tensile strength(N/5 20cm)

Warp

650

700

800

1800

1800

1800

Weft

1150

1200

1300

1800

1800

1800

Tensile Elongation ()

Warp

35

35

35

10

10

10

Weft

55

55

55

10

10

10

Broken strength
(Mpa/min)

2.55

2.50

2.40

3.20

3.10

2.95

Working Temperature()

 260

 260

Short time Working temperature()

280

280

Anti-acid

Excellent

Excellent

Anti-alkali

Fair

Fair

Anti-abrasion

Excellent

Excellent

The stability of water solution

Medial

Medial

Finishing treatment

High temperature hot pressing, Singeing

High temperature hot pressing, Singeing, membrane.


Easily Dedusting High Temperature P84/Polymide Non Woven Geotextile Filter Fabric Easily Dedusting High Temperature P84/Polymide Non Woven Geotextile Filter Fabric Easily Dedusting High Temperature P84/Polymide Non Woven Geotextile Filter Fabric

FQA
Q:Are you manufacturer or trading company?
 A:We are the manufacturer which have more than 25 years of production experience.

Q: Can I ask one piece of samples before place order?
 A:Yes, free samples are available for your review.

Q:What is your payment?
  A:Our company accept both T/T & L/C payment. For the details, we could discuss with each other.

Terms and Service
     a. Trade terms: FOB, CIF, CNF,DAP etc.
     b. Payment terms: 30% pre-paid by T/T, 70% balance against BL copy by T/T or L/C at sight.
     c. Loading port:  Ningbo or Shanghai Port
     d.MOQ: 100 square meters
     e. Delivery: 7--18 days after the order confirmed, the detail lead time according to the order QTY.



Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
