China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Looking for high-quality galvanized steel coils? Our factory produces China's most popular carbon steel and galvalume coils with various coatings. We are your reliable source for ASTM A653 Z275 color coated zinc/galvanized steel coils.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Detailed Photos
  • Our Advantages
  • Product Application
  • Packaging & Shipping
  • Certifications
  • Our Service
Overview

Basic Info.

Model NO.
DX51D, DX52D SGCC, SGCH Z30-275g/m2
Application
Building Materials
Edge
Slit edge
Stock
Stock
Zinc Coating
30-275G/M2
Surface
Coated, Embossed,Brushed, Polished, Anodized
Coil ID
508/610mm
Coil Weight
3-8ton or as Per Request
Hardness
Middle Hard
Color
Red,Blue,White,Brown,Green etc.Ral Code
Coating
PE/PVDF
Trade Term
EXW/Fca/Fob/CFR/CIF/DDU
Payment Term
T/T or L/C
Inspection
SGS/BV/TUV
Inventory
8000ton
Delivery Time
Within 7-15 Days
Capacity
3000000ton/Year
Quality
Superior Quality Guaranteed
Package
Waterproof Iron Package with Several Steel Strip
Transport Package
Standard Export Package
Specification
DX51D SGCC G550 G350 Z30-275
Trademark
CHI STEEL
Origin
China
HS Code
72107000
Production Capacity
300000ton/Year

Product Description

China Most Popular Carbon Steel Coil Galvalume Coil SGCC DX51D PPGI PPGL Gl Galvanized Steel Strip/Coil  ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Product Description

PPGI Coil is a type of pre-painted galvanized iron coil that is widely used in various industries such as construction, automotive, and home appliances. It is a high-quality product that is made by coating galvanized steel with layers of organic paint, which provides excellent corrosion resistance and aesthetic appeal.

Color Prepainted Galvanized PPGI Steel Coil is a product made of cold rolled steel plate and galvanized steel plate by surface pretreatment (degreasing, cleaning, chemical conversion), continuous coating (roll coating), baking and cooling. Coated steel sheet has light weight, beautiful appearance, good corrosion resistance and can be processed directly. It provides a new raw material for construction, shipbuilding, vehicle manufacturing, household electrical appliances, electrical industry, etc. Chinese supplier G350 0.35mm size ppgi coil colour coated sheet for saled role in replacing wood with steel, efficient construction, energy saving, pollution prevention and other goManufacturer of pre painted galvanized color coated ppgl ppgi steel sheets for afrciaod results.

Some of the key features of our PPGI Coil products include high durability, excellent color retention, and easy maintenance. They are also highly resistant to scratching, chipping, and fading, making them ideal for a variety of applications.

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil
China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Product Parameters

Cold Rolled Color Coated Galvanized(PPGI) Steel Coil Specification:

Coating Type   Coating Thickness     (UM)     Pencil   Hardness 60° Coating Specular   Gloss 180° Bend Reverse Impact
     (J)
   Salt -Resistant
    (h)
Low Middle High Thickness ≤ 0.75mm   (thickness of steel window material ≤ 0.80mm)
   A Grade     B Grade
Polyester ≥20 ≥F <40 40~70 >70 ≤5T ≤3T ≥9 ≥500
Silicon   Modified Polyester ≥20 ≥F <40 40~70 >70 ≤5T ≤3T ≥9
High   Durability Polyester ≥20 ≥HB <40 40~70 - ≤5T ≤2T ≥9 ≥1000
Polyvinyliden  Fluoride ≥20 ≥HB <40 40~70   ≤5T ≤2T ≥9 ≥1000

The   recommended substrates for different purposes and the weight of the coating   commonly used for the substrates are shown in the table below
                         Serial   Number Purpose Base Plate Coating Weight (g/m2)
                                    1 External use of   buildings Hot dip galvanized sheet 90/90
                                    2 Steel windows for building Hot dip galvanized   sheet 90/90
Electro galvanized sheet 60/60
                                    3 Household appliances   and furniture Electro galvanized   sheet 20/20
                                    4 building Hot dip aluminum zinc   plating 75/75

Unit: mm available specifications
Project Nominal Size
Nominal Thickness 0.3~2.0
Nominal Width 700~1550
Nominal Length Of Steel Plate 1000~4000
The inner   diameter of steel coil is usually 610mm. If the inner diameter of steel coil   is required to be 508mm, it shall be negotiated during ordering

Location Category Value
Executive standard National standard GB/T12754-2019
American Standard/European Standard ASTM A792M
Cold Rolled Substrate Width specification Cold rolled substrate thickness Including metallized layer, the thickness after painting Label thickness
1200mm ≥0.41mm ≥0.46mm ≥0.45mm
Size deviation Width tolerance Upper deviation +4mm
Lower deviation 0
thickness Upper deviation +0.05mm
Lower deviation 0
Yield Strength >300MPA
tensile strength 270-500MPA
elongation after break More than 20%
Steel coil inner diameter Standard: 508mm,Except for other agreements
  Metal Coating alloy composition AlZnMg or galvanized AlMg
Total Weight of Plating Both Sides (Outside/Inside) 150g/ (75/75 or 85/65)
Neutral salt spray test The surface of the board (without passivation, anti-fingerprint and other treatments on the surface) has a neutral salt spray test of more than or equal to 2500 hours, and there is no red rust on the surface.
When the salt spray test on the wound surface (end surface) is greater than or equal to 1200, there is no red rust on the surface.
PPGI Paint PE coating structure standard (μm) Paint structure 2/1 outside ≥25
Inside ≥7
pencil hardness Not less than HB
Specular Gloss of Topcoat Glossiness of finish paint mirror surface: ≥40 degrees
T bend value 2T
Impact energy Not less than 9J
Neutral salt spray test Greater than or equal to 1500h without bubbles
UVB-313 greater than or equal to 700h
PPGI Use Environment humidity 20% to 90%
temperature Min -45°C, Max 43°C
unit ammonia <30ppm
unit carbon dioxide <7000ppm
unit oxygen 21%
unit hydrogen sulfide <5ppm

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Detailed Photos

Color coated steel coil(PPGI) is hot galvanized plate, hot galvanized aluminum zinc plate, galvanized plate and other substrates, the surface pretreatment (chemical degreasing and chemical conversion treatment), on the surface coated with a layer or several layers of organic coating, and then after baking curing products. Because coated with a variety of different colors of organic paint color steel coil plate named, referred to as color coated coil. The use of hot dip galvanized steel strip as the base material of color coating steel strip in addition to the zinc layer protection, the zinc layer of the organic coating to cover and protect the rust of the steel strip, the service life is longer than galvanized strip, about 1.5 times.

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil
China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

*Topcoat (finishing) which provides color, pleasing appearance and appearance and a barrier film to enhance long-term durability.

*Primer coat to prevent undercutting of paint and enhance corrosion resistance.

*Pretreatment layer applied for good adhesion and to enhance corrosion resistance.

*Base steel sheet.

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Our Advantages

Complete range
For the use of color steel coils, we have to choose different types of color steel coils to manufacture different PPGI. Regarding it, I have to briefly introduce the types of color steel coils, which are divided into five categories. That is, home appliances, optical materials, decorative materials, building materials, and packaging. Among them, the production process of color steel coils for home appliances is the most delicate and perfect.

Good performance
Chicago color coated steel plate refers to the coating product obtained by applying organic paint to the surface of thin steel plate. PPGI has good anti-corrosion and decorative properties, as well as the good formability and processing properties of organic polymers and steel plates.

5S management
Before PPGI production, each post cleans the surrounding environment, ground sanitation, equipment spot inspection and each roller surface that directly affects the surface quality of the product in the working area according to the "Workshop 5S Management System" to ensure personal safety. At the same time, prepare tools, auxiliary materials, raw materials, etc. within the specified time. Ensure that the ground in the work area is free from dust, water and oil, ensure that the equipment is in the best condition and that the materials are used correctly.

Strictly check
PPGI image defects, surface defects, trace defects, edge defects, gold plating defects, size defects, coating defects, uneven defects, contamination defects, coating uneven defects, process defects, coating surface defects, physical property defects.

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil
China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Product Application

Color coated PPGI galvanized steel coil is widely used for making corrugated roofing sheet, ceiling channel, industrial refrigeration, cold storage, door panel, sandwich panel, PU panel and etc.

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Packaging & Shipping

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel CoilChina Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Certifications

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Our Service

China Most Popular Carbon Steel Coil Galvalume Coil SGCC Dx51d PPGI PPGL Gl Galvanized Steel Strip/Coil ASTM A653 Z275 Color Coated Zinc/Galvanised Steel Coil

Why Choose Us:


1.Quality first: production and inspection in strict accordance with production standards;

2.Price advantage: discounts based on real market prices;

3.Transaction security: There will be no loss of customer funds;

4.After-sales guarantee: the customer's problem is our problem;

5.Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.

6.Complete specifications, adequate inventory

7.One-stop procurement

8.Delivery time usually within 7-15 days after receipt of advance payment



Superior quality, Immediate delivery, Strict production and inspection, high quality guaranteed, First class service!


If you're looking for a reliable and high-quality PPGI/PPGL Coil supplier,contact us online to learn more about our products and services.
